Jazzy® Carbon 27X
The Jazzy® Carbon 27X is a power wheelchair that folds vertically thanks to its innovative X-frame design. Weighing in at approximately 27.5 lbs. without the battery, it’s the ideal mobility device for journeys near and far. The strong carbon fiber frame makes it durable, portable, and safe so you can discover your independence and travel worry-free.
Features
Specification
Features
Jazzy® Carbon 27X Features:
Weighs about 27.5 lbs. without the battery
275 lb. weight capacity
Top speed up to 3.7 mph
Battery range of up to 8 miles
X-frame design allows the unit to fold flat in vertical position
Advanced, durable, and lightweight carbon fiber frame
Folded dimensions: 34” L x 12” W x 30” H
Flip up, lightweight, carbon fiber arms
Collapsible back handles
Adjustable footrests
Airline-compliant lithium battery** (10 Ah only)
Storage pocket in seat back
Cushion and adjustable lap belt (Standard)
Carbon fiber storage with cup holder (Standard)
Programmable quick disconnect joystick (Standard)
K0899 Power Mobility Device, not coded by DME PDAC or does not meet criteria.
Available Color: Black
*This product is an FDA Class II Medical Device designed to aid individuals with mobility impairments.
**Note: Transport of this item on commercial aircraft is subject to federal regulations and airline policy. Please consult your airline prior to your flight to ensure your Jazzy® Carbon 27X and its lithium battery are permitted
Weighs about 27.5 lbs. without the battery
275 lb. weight capacity
Top speed up to 3.7 mph
Battery range of up to 8 miles
X-frame design allows the unit to fold flat in vertical position
Advanced, durable, and lightweight carbon fiber frame
Folded dimensions: 34” L x 12” W x 30” H
Flip up, lightweight, carbon fiber arms
Collapsible back handles
Adjustable footrests
Airline-compliant lithium battery** (10 Ah only)
Storage pocket in seat back
Cushion and adjustable lap belt (Standard)
Carbon fiber storage with cup holder (Standard)
Programmable quick disconnect joystick (Standard)
K0899 Power Mobility Device, not coded by DME PDAC or does not meet criteria.
Available Color: Black
*This product is an FDA Class II Medical Device designed to aid individuals with mobility impairments.
**Note: Transport of this item on commercial aircraft is subject to federal regulations and airline policy. Please consult your airline prior to your flight to ensure your Jazzy® Carbon 27X and its lithium battery are permitted
Specification
Model
Jazzy® Carbon 27X
Weight Capacity 275 lbs.
Maximum Speed1 Up to 3.7 mph
Ground Clearance3 3″
Turning Radius3 35.4″
Overall Length3 41″
Overall Width3 23″
Suspension Full Front and Rear Suspension
Front Wheels 7″
Rear Wheels 10″
Range per Charge1,2 Up to 8 Miles per charge
Product Weight Without Batteries3,5 27.5 lbs. without batteries
Standard Seating3 Cushioned back with removable seat cushion
Folded Dimensions 34″ L x 12″ W x 30″ H
Drivetrain/Motor Output> 24V 150W
Braking System Regenerative and electromechanical
Battery Requirements6 24V 10Ah
Battery Weight4 3.5 lbs.
Battery Charger 3.5 Amp
HCPCS Codes K0899 Power Mobility Device, not coded by DME PDAC.
DME providers are responsible for determining appropriate billing codes when submitting for insurance reimbursement. HCPCS codes provided should not be considered as legal advice and not guarantee reimbursement. Payer coding, coverage and bundling guidelines may apply.
Warranty Frame: 5-year limited
Drivetrain: 13-month limited
Electronics: 13-month limited
Battery: 13-month
Weight Capacity 275 lbs.
Maximum Speed1 Up to 3.7 mph
Ground Clearance3 3″
Turning Radius3 35.4″
Overall Length3 41″
Overall Width3 23″
Suspension Full Front and Rear Suspension
Front Wheels 7″
Rear Wheels 10″
Range per Charge1,2 Up to 8 Miles per charge
Product Weight Without Batteries3,5 27.5 lbs. without batteries
Standard Seating3 Cushioned back with removable seat cushion
Folded Dimensions 34″ L x 12″ W x 30″ H
Drivetrain/Motor Output> 24V 150W
Braking System Regenerative and electromechanical
Battery Requirements6 24V 10Ah
Battery Weight4 3.5 lbs.
Battery Charger 3.5 Amp
HCPCS Codes K0899 Power Mobility Device, not coded by DME PDAC.
DME providers are responsible for determining appropriate billing codes when submitting for insurance reimbursement. HCPCS codes provided should not be considered as legal advice and not guarantee reimbursement. Payer coding, coverage and bundling guidelines may apply.
Warranty Frame: 5-year limited
Drivetrain: 13-month limited
Electronics: 13-month limited
Battery: 13-month
